Hot sale solid and firm curved shape solar roof tiles 32w glass waterproof solar energy system solar panel module for building

Hot sale solid and firm curved shape solar roof tiles 32w glass waterproof solar energy system solar panel module for building

Specific attributes

Place of Origin: China
Product Name:  32W BIPV Glass Solar Panel
Type: Double-glass, BIPV
Panel Efficiency: 20.54%
Panel Dimensions: 721*500*14mm
Cell size: 166mm*166mm
Color: Black/red(25w)/green(23w)
Shape: three arched
Material: double glass
Maximum Power(Pmax): 32W
Open Circuit Voltage(Voc):10.6V
Short Circuit Current(lsc):4.0A
Maximum Power Voltage(Vmp):8.9V
Maximum Power Current(lmp):3.6A
Frame: Frameless
Fire-proof level: Class A
Weight 6.5kg/PCS
Weight/m2: 22KGS
Connector: PV Compatible Connector
Certificate: TUV/CE

Details Images

Custom made solar panel example
