Specification
Arch Design, Noble And Elegant
Appearance dimension :2100/height*100/dia mm ( height is the arch height )
style: Arched shape sunpower-glass solar panel
Glass type: tempered glass
Component thickness :5(±1) mm
Unit component weight :1.7kg
Item: XXR-60W
Single product power :60W
Single product Vmpp:9v
Impp(A):6.66A
Voc: 10.6V
Isc: 7.3A
Color : zero carbon black , or customized
Linear power guarantee : 10 years
Working life :25 years
Load level :5400Pa( maximum static load on the front , including snow load and wind load )
Waterproof grade :IP67
Fire rating : A
Windproof grade : F
Hail resistance : maximum diameter 25mm, impact speed 23m/ s
Operating temperature :-40° Cto +85° C
![customized Arched shape structure](/./Uploads/images/products/2024-06-06/en-glass-173509.jpg)
![customized Arched shape solar panel applicate](/./Uploads/images/products/2024-06-06/en-Se-173613.jpg)
The panel size/voltage/shape/power/connector...all can be customized.. please contact us if you need any othersSOME STEPS TO CUSTOM YOUR SOLAR PANELStep 1: Tell us your requests about power/voltage/shape/size.....(contact us if you are not sure).
Step 2: check our optional design and quotation
Step 3: confirm samples and bulk production
Custom made solar panel example
![customized Arched shape solar panel examples](/./Uploads/images/products/2024-06-03/en-1-171925.jpg)
Features of different coating
![recommend customized Arched shape coating](/./Uploads/images/products/2024-06-13/en-epoxy-glass-102224.jpg)
![common solat panel coating](/./Uploads/images/products/2024-06-13/en-ETFE-PET-102255.jpg)
Connector ---Can use different connectors
![customized Arched shape connectors](/./Uploads/images/products/2024-06-03/en-4-Connectors-173614.jpg)
![recommend customized Arched shape package](/./Uploads/images/products/2024-06-03/en-7-package-174543.png)
