50W fotovoltaico in cloud using normally built in bypass diodes pannelli fotovoltaico

50W fotovoltaico in cloud using normally built in bypass diodes pannelli fotovoltaico

Production description

Product name: 50W pannelli fotovoltaico built in bypass diodes
Panel Dimension: 680*400*25mm
Material: Monocrystaline Silicon
Weight: 4kg
Power: 50w
Solar cell: A grade cutting 156.75mm
Cell series: 3*12 156*45mm
Cell Efficiency: 24.2%
Keyword: bypass diodes pannelli fotovoltaico
Frame: Aluminum
Junction Box: IP 67 rated waterproof
Vmpp: 20.52V
Impp: 2.437A
Voc: 24.21V
Isc: 2.68A
Power tolerance: 3%
Temperature Coefficient Pmax(%/K): -0.41
Temperature Coefficient Voc(%/K): -0.32
Temperature Coefficient Isc(%/K):0.04
Maximum System Voltage(V): 1000VDC
OEM: Customized Solar Panel Aavilable
Operate Temperature: -40℃~ +85℃

The panel size/voltage/shape/power/connector...all can be customized.. please contact us if you need any others
SOME STEPS TO CUSTOM YOUR SOLAR PANEL
Step 1: Tell us your requests about power/voltage/shape/size.....(contact us if you are not sure).
Step 2: check our optional design  and quotation
Step 3: confirm samples and bulk production

Custom made solar panel example

Features of different coating

Connector ---Can use different connectors

Applications
