Lightweight high - conversion 200W ETFE mono solar panel built in bypass diode transparent flexible pv solar panel
Lightweight high - conversion 200W ETFE mono solar panel built in bypass diode transparent flexible pv solar panel Lightweight high - conversion 200W ETFE mono solar panel built in bypass diode transparent flexible pv solar panel

Lightweight high - conversion 200W ETFE mono solar panel built in bypass diode transparent flexible pv solar panel

Product ID : XXR-24175
Product Attributes :

Lightweight ETFE mono solar panel include bypass diode, power watt 200w, other power watt available, OEM solar panel

Product Description

Lightweight high - conversion 200W ETFE mono solar panel built in bypass diode transparent flexible pv solar panels

Product Description

Production Name: Lightweight High conversion Custom ETFE flexible solar panel inside bypass diode
Country of origin:China
Panel Material:ETFT+EVA+cell +EVA+PET
Panel Size: 1470*670*3mm
Cell Type: MONO 158.75mm
Power: 200W
Power tolerance: 0~3W
Number of cells: 36(9*4)pcs s
Module Efficiency:19%+ 27PCS  3*9 series
Voltage: 36V
Current: 5.55A
Open circuit voltage: 42.48V
Short circuit current: 6.11A
Connector: male&female connector
Junction Box: Waterproof IP67 Rated
Weight:2.45KG
Operating Temperature: -40℃ ~+85℃

ETFE solar panel structure image

diode solar panel

what is bypass diodes meaning use for solar panel

Product Advantages
1、Using American imported sunpower/ME3 battery cells, high efficiency conversion rate>24%, providing the maximum power and the highest charging current among similar products.
2、Product technology: each two solar panels installed a bypass diode, when the object blocking one of the battery cell current can flow through the bypass diode the next set of cells, to avoid the solar energy to produce hot spot effect caused by the solar panels surface fire phenomenon; at the same time, the voltage of the entire solar panels only reduces the voltage of the blocked battery cell and the current, which greatly improves the charging current of the entire system.
3, the surface of the use of Japanese imports of thin film ETFE material, corrosion resistance, anti-cracking, anti-scratch, long life, suitable for use in harsh environments. It is the best choice for electric yacht.



The panel size/voltage/shape/power/connector...all can be customized.. please contact us if you need any others
SOME STEPS TO CUSTOM YOUR SOLAR PANEL
Step 1: Tell us your requests about power/voltage/shape/size.....(contact us if you are not sure).
Step 2: check our optional design  and quotation
Step 3: confirm samples and bulk production


Custom made solar panel example
customized solar panel examples



This product is customized type, suggest bellow for your battery Or contact us.
How to confirm the panel voltage





Features of different coating
etfe and pet solar panel coating features
others coating process





Connector ---Can use different connectors
various type connectors for solar panel
