Photovoltaic Sunpower 300W maxeon 30V lightweight Customized solar panels for solar bicycle trailer

Key Features
Sunpower lightweight customized ETFE solar panels can be widely installed on yacht, bicycle trailer ,RV, boat,barge,car etc, outdoor places
Item No.   :   XXR-SFSP- ETFE-300W
Size(mm) :   1650*830*3mm  (10*5 series)  sunpower 161.7*161.7mm
Max Power(Pmax)  :   300W
Cell Type :    Sunpower 161.7*161.7mm (6*6 inch)
Number of cells     50 (10*5) pcs
Weight  :  4.6KG
Max Power Voltage(Vmp)  :  30V
Max Power Current(Imp)    :10A
Open Circuit Voltage(Voc)  :  35.4V
Short Circuit Current (Isc)  :    11A
Module Efficient STC (%)  :   22.8%
Operating Temperature(℃)  :  -40℃ ~+85℃
Max system voltage  :  1000VDC (IEC)
Max series fuse rating   : 15A
Power tolerance :   0~+3W
Temperature coefficient of Pmax :   -0.42%/℃
Temperature coefficient of Voc  :  -0.32%/℃
Temperature coefficient of Isc :   0.05%/℃
Nominal operating cell temperature(NOCT)  :  45 ± 2℃
STC: Irradiance 1000W/m^2;       Cell Temperature: 25℃;        AM=1.5
Place of Origin : Guangdong, China
Brand Name : OEM
Type：Customized Solar Panel
sunpower solar panel Material：sunpower solar cell + eva+backsheet+junction box etc
flexible panel Warranty: 8 years
Junction Box:    Waterproof IP67 Rated
 Output Cables:    TUV 1*4.0mm^2, Length: 900mm



Packaging & delivery

Package size per batch: 122X67X21 cm （4pcs  packed into one carton ）

Gross weight per batch: 25 kg

Package Type: each piece solar panel individual packing, 5 pcs into a bigger carton. inside with strong foam to protect each pcs solar panel outside with packing belt.
