Full Black Solar Photovoltaic Roof Tiles Flat with Al frame Sunpower solar cell maxeon GEN 5 Glass Solar Panel on house roof solar solutions

Cell size:sunpower 161.7mmx161.7mm

Type:Solar Tile

Warranty:10 Years For Material And Processing

Place of Origin :China

Panel Dimensions :700x 710 x25 mm

Brand Name: XXR,OEM

Model Number: XXR-BC 100W

Product name: IBC Solar Panel Roof Tiles Solar Panel

Junction Box :IP67

Weight :6kg

Single product power :100W

Power per level: 100w

Vmpp: 9.5v

Component thickness: 6mm

Fire rating: A

Windproof grade: F

Component weight per square meter: 9kg

Color: black

Port :Shenzhen

Linear power guarantee: 25 years
Load level:5400Pa(maximum static load on the front, including snow load and wind load)
Waterproof grade: IP67
Fire rating: A
Windproof grade: F
Hail resistance: maximum diameter 25mm, impact speed 23m/s
Operating temperature:-40~+85℃

TECHNICAL PARAMETER
Specification	700mm(length), 710mm(width)
Weight	6.0kg
Linear power guarantee	25 Year
Power	100W
Short-circuit current	10.5A
Load rating	5400Pa
Waterproof rate	IP67
Vmpp	9.5V
Wind protection rating	F
Hail resistance rating	4 Class
Operating temperature	-40°C to +85°C
